ELECTRICAL DATA @STC

Model: SR-M672440HLP

Maximum Power Pmpp [Wp]: 440

Maximum Power Tolerance (%): +≥3%

Voltage at maximum Power Vmpp[V]: 40.99

Open circuit Voltage Voc [V]: 49.28

Current at maximum Power Impp [A]: 10.74

Short circuit Current Isc [A]: 11.35

NOCT [deg. C]: ±2

Module Efficiency [%]: 20.25 %

Cells Efficiency: 20.47 %

Number of Cells: 144 (6 x 24)

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: SR-M672445HLPB

Maximum Power Pmpp [Wp]: 445

Maximum Power Tolerance (%): +≥3%

Voltage at maximum Power Vmpp[V]: 41.18

Open circuit Voltage Voc [V]: 50.12

Current at maximum Power Impp [A]: 10.81

Short circuit Current Isc [A]: 11.34

NOCT [deg. C]: ±2

Module Efficiency [%]: 20.48 %

Cells Efficiency: 20.48 %

Number of Cells: 144 (6 x 24)

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: SR-M672445HLP

Maximum Power Pmpp [Wp]: 445

Maximum Power Tolerance (%): +≥3%

Voltage at maximum Power Vmpp[V]: 22.36

Open circuit Voltage Voc [V]: 49.86

Current at maximum Power Impp [A]: 10.81

Short circuit Current Isc [A]: 11.41

NOCT [deg. C]: ±2

Module Efficiency [%]: 20.71 %

Cells Efficiency: 20.71 %

Number of Cells: 144 (6 x 24)

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: SR-M672450HLP

Maximum Power Pmpp [Wp]: 450

Maximum Power Tolerance (%): +≥3%

Voltage at maximum Power Vmpp[V]: 41.39

Open circuit Voltage Voc [V]: 50

Current at maximum Power Impp [A]: 10.81

Short circuit Current Isc [A]: 11.48

NOCT [deg. C]: ±2

Module Efficiency [%]: 20.71 %

Cells Efficiency: 20.71 %

Number of Cells: 144 (6 x 24)

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 040

Maximum Power Pmpp [Wp]: 40

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 18.06

Open circuit Voltage Voc [V]: 21.85

Current at maximum Power Impp [A]: 2.21

Short circuit Current Isc [A]: 2.39

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 030

Maximum Power Pmpp [Wp]: 30

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 17.80

Open circuit Voltage Voc [V]: 21.54

Current at maximum Power Impp [A]: 1.69

Short circuit Current Isc [A]: 1.84

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 060

Maximum Power Pmpp [Wp]: 60

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 18.06

Open circuit Voltage Voc [V]: 21.94

Current at maximum Power Impp [A]: 3.32

Short circuit Current Isc [A]: 3.59

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 050

Maximum Power Pmpp [Wp]: 50

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 18.06

Open circuit Voltage Voc [V]: 21.94

Current at maximum Power Impp [A]: 2.77

Short circuit Current Isc [A]: 2.99

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 075

Maximum Power Pmpp [Wp]: 75

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 18.06

Open circuit Voltage Voc [V]: 21.94

Current at maximum Power Impp [A]: 4.15

Short circuit Current Isc [A]: 4.49

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 300

Maximum Power Pmpp [Wp]: 300

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 45.4

Open circuit Voltage Voc [V]: 36.45

Current at maximum Power Impp [A]: 8.22

Short circuit Current Isc [A]: 8.80

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 72

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 250

Maximum Power Pmpp [Wp]: 250

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 37.3

Open circuit Voltage Voc [V]: 30.7

Current at maximum Power Impp [A]: 8.14

Short circuit Current Isc [A]: 8.71

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 60

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 200

Maximum Power Pmpp [Wp]: 200

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 36.45

Open circuit Voltage Voc [V]: 30

Current at maximum Power Impp [A]: 6.67

Short circuit Current Isc [A]: 7.2

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 60

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 260

Maximum Power Pmpp [Wp]: 260

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 37.5

Open circuit Voltage Voc [V]: 30.94

Current at maximum Power Impp [A]: 8.4

Short circuit Current Isc [A]: 8.99

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 60

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 125

Maximum Power Pmpp [Wp]: 125

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 22.36

Open circuit Voltage Voc [V]: 18.40

Current at maximum Power Impp [A]: 6.69

Short circuit Current Isc [A]: 7.34

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 150

Maximum Power Pmpp [Wp]: 150

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 22.36

Open circuit Voltage Voc [V]: 18.40

Current at maximum Power Impp [A]: 8.15

Short circuit Current Isc [A]: 8.80

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 100

Maximum Power Pmpp [Wp]: 100

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 22.05

Open circuit Voltage Voc [V]: 18.15

Current at maximum Power Impp [A]: 5.51

Short circuit Current Isc [A]: 5.95

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

310Wp Solar PV Module

ELECTRICAL DATA @STC

Model: INV 310

Maximum Power Pmpp [Wp]: 310

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 45.74

Open circuit Voltage Voc [V]: 37.19

Current at maximum Power Impp [A]: 8.34

Short circuit Current Isc [A]: 8.92

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 72

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

ELECTRICAL DATA @STC

Model: INV 320

Maximum Power Pmpp [Wp]: 320

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 46.08

Open circuit Voltage Voc [V]: 37.92

Current at maximum Power Impp [A]: 8.44

Short circuit Current Isc [A]: 9.03

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 72

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

20 Ah Rated Capacity @ C10, 12V

Warranty - 36 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

It has high purity, corrosion-resistant proprietary spine alloy composition for long battery life

Extra-strong, flexible oxidation-resistant gauntlet for better performance and long life

Puncture-resistant polyethylene separator which minimize the possibility of internal short circuits.

100 Ah Rated Capacity @ C10, 12V

Warranty - 60 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

40 Ah Rated Capacity @ C10, 12V

Warranty - 60 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

80 Ah Rated Capacity @ C10, 12V

Warranty - 60 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

60 Ah Rated Capacity @ C10, 12V

Warranty - 60 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

Rated AC power: 900VA, 12V

Operating Voltage 100-290V

Max supported panel power: 12V upto 1000 Wp

Charge Controller Rating - 40 Amp/12V, with 98% efficiency for fast charging

Supports single battery

24 Month Warranty

Sine wave Solar hybrid UPS with 80% efficiency

Savings of 25-30% on electricity bills by reducing charging time with the help of Intelligent Logic Control

Power savings of 1.5 - 3 units per day* with the help of Intelligent Solar Optimization Technique (iSOT).

Fast battery charging through i-Charge Technology, on grid power, if case of long power cuts

Sine wave output for safety of your sensitive appliances and noiseless operations.

Battery charging commences from 110 Volt which makes it suitable for both urban and rural areas

Supports ECO Mode & UPS mode

Extensive Safety and Protection through built in features for monitoring the health of your batteries and protects them against deep discharge, overcharge and short-circuit. The Main fuse for protection against excessive current thereby ensuring safety of your sensitive appliances.

Battery type selector to configure charging currents as per connected battery.

Rated AC power: 1100VA, 24V

Operating Voltage 100-290V

Max supported panel power: 24V upto 1000 Wp

Charge Controller Rating - 20 Amp/24V, with 98% efficiency for fast charging

Supports Double battery

24 Month Warranty

Sine wave Solar hybrid UPS with 85% efficiency

Savings of 25-30% on electricity bills by reducing charging time with the help of Intelligent Logic Control

Power savings of 1.5 - 3 units per day* with the help of Intelligent Solar Optimization Technique (iSOT).

Fast battery charging through i-Charge Technology, on grid power, if case of long power cuts

Sine wave output for safety of your sensitive appliances and noiseless operations.

Battery charging commences from 110 Volt which makes it suitable for both urban and rural areas

Supports ECO Mode & UPS mode

Extensive Safety and Protection through built in features for monitoring the health of your batteries and protects them against deep discharge, overcharge and short-circuit. The Main fuse for protection against excessive current thereby ensuring safety of your sensitive appliances.

Battery type selector to configure charging currents as per connected battery.

120 Ah Rated Capacity @ C10, 12V

Warranty - 60* Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

It has high purity, corrosion-resistant proprietary spine alloy composition for long battery life

Extra-strong, flexible oxidation-resistant gauntlet for better performance and long life

Puncture-resistant polyethylene separator which minimize the possibility of internal short circuits.

200 Ah Rated Capacity @ C10, 12V

Warranty - 36* Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

It has high purity, corrosion-resistant proprietary spine alloy composition for long battery life

Extra-strong, flexible oxidation-resistant gauntlet for better performance and long life

Puncture-resistant polyethylene separator which minimize the possibility of internal short circuits.

150 Ah Rated Capacity @ C10, 12V

Warranty - 60* Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

40 Ah Rated Capacity @ C10, 12V

Warranty - 36 Months

Tubular plate Technology - Next generation tall tubular battery with better charge acceptance and long Back up

Long cycles (1500 @80% DOD, 5000 @ 20% DOD), ensuring design life

Longer life without discharge with self-discharge rate of 3% per month STC.

Efficient battery with Higher AH efficiency > 90%, and WH efficiency > 80%

Low maintenance with a topping frequency of 8-10 months, low maintenance with level indicators

Manufactured with high corrosion resistant and robust spine technology using the advanced and state-of-the-art HADI high pressure (at 100 bar) spine casting machines, which ensure a super fine grain structure, for strength, long life and highest reliability

Designed with thicker positive plates and 20% more electrolyte to withstand power outage

It has high purity, corrosion-resistant proprietary spine alloy composition for long battery life

Extra-strong, flexible oxidation-resistant gauntlet for better performance and long life

Puncture-resistant polyethylene separator which minimize the possibility of internal short circuits.

• Rated AC power: 900VA, 12V
• Operating Voltage 100-290V
• Max supported panel power: 12V upto 1000 Wp
• Charge Controller Rating - 40 Amp/12V, with 98% efficiency for fast charging
• Supports single battery
• 24 Month Warranty
• Sine wave Solar hybrid UPS with 80% efficiency
• Savings of 25-30% on electricity bills by reducing charging time with the help of Intelligent Logic Control
• Power savings of 1.5 - 3 units per day* with the help of Intelligent Solar Optimization Technique (iSOT).
• Fast battery charging through i-Charge Technology, on grid power, if case of long power cuts
• Sine wave output for safety of your sensitive appliances and noiseless operations.
• Battery charging commences from 110 Volt which makes it suitable for both urban and rural areas
• Supports ECO Mode & UPS mode
• Extensive Safety and Protection through built in features for monitoring the health of your batteries and protects them against deep discharge, overcharge and short-circuit. The Main fuse for protection against excessive current thereby ensuring safety of your sensitive appliances.
• Battery type selector to configure charging currents as per connected battery.

ELECTRICAL DATA @STC

Model: INV 010

Maximum Power Pmpp [Wp]: 10

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 17.60

Open circuit Voltage Voc [V]: 21.3

Current at maximum Power Impp [A]: 0.57

Short circuit Current Isc [A]: 0.62

NOCT [deg. C]: ±2 45  Module Efficiency [%]: 13.0

Cells Efficiency: 18%

Number of Cells: 36
The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

LUMINAIRE

SYSTEM WATTAGE( LED + DRIVER) : 40W (120 LED’s of 0.5W with Output of 40W)

SYSTEM OUT PUT(AFTER ACCOUNTING ALL LOSES) : 5600 Lumens

LED LEVEL EFFICIENCY :140 LUMENS/WATT

LED LIFE :50,000 Hours

DRIVER EFFICIENCY :85%

DRIVER TYPE :DC-DC

TOTAL SYSTEM WARRANTY :3 YEARS WARRANTY

HOUSI :IP 65 ALUMINIUM DIE-CAST HOUSING, IP66

LUMINAIRE ARM :Powder Coated

SOLAR PANEL

CAPACITY :125 Wp

SOLAR CELLS :POLYCRYSTALLINE SILICON CELSS

SOLAR CELL EFFICIENCY :13.50%

JUNCTION BOX :IP65, IP66

MOUNTING FRAME :POWDER COATED

COUNTRY OF MANUFACTURER :INDIA

BATTERY AND BATTERY BOX

CAPACITY :12V, 30,000 mAh LiFePo4 BATTERY

TYPE :Lithium Ferrous Phosphate Battery

PERMITTED DEPTH OF DISCHARGE :70%

BATTERY BACKUP :12 HOURS

MOUNTING POSITION :IN BUILT BOX WITH P.V. PANEL STRUCTURE

BATTERY BOX MATERIAL & PROTECTION :M.S. SHEET WITH POWDER COATED 1 mm THK

CHARGE CONTROLLER

TYPE :PWM Based

RATING :12.8V NOMINAL, LOAD 2.1A MAX.SMPS FOR LED LOAD

EFFICIENCY :85%

STAND BY CURRENT :OUTPUT VOLTAGE DROP

LUMINAIRE

SYSTEM WATTAGE( LED + DRIVER) :30W

SYSTEM OUT PUT(AFTER ACCOUNTING ALL LOSES) : 4000 Lumens

LED LEVEL EFFICIENCY :200 LUMENS/WATT OSARAM GW JDSTS2.EM Led

LED LIFE :50,000 Hours

DRIVER EFFICIENCY :85%

DRIVER TYPE :DC-DC

TOTAL SYSTEM WARRANTY :3 YEARS WARRANTY

HOUSI :IP 65 ALUMINIUM DIE-CAST HOUSING, IP66

LUMINAIRE ARM :Powder Coated

SOLAR PANEL

CAPACITY :100 Wp

SOLAR CELLS :POLYCRYSTALLINE SILICON CELSS

SOLAR CELL EFFICIENCY :13.50%

JUNCTION BOX :IP65, IP66

MOUNTING FRAME :POWDER COATED

COUNTRY OF MANUFACTURER :INDIA

BATTERY AND BATTERY BOX

CAPACITY :18000 mAh LIFePo4 BATTERY

TYPE :Lithium Ferrous Phosphate Battery

PERMITTED DEPTH OF DISCHARGE :70%

BATTERY BACKUP :12 HOURS

MOUNTING POSITION :IN BUILT BOX WITH P.V. PANEL STRUCTURE

BATTERY BOX MATERIAL & PROTECTION :M.S. SHEET WITH POWDER COATED 1 mm THK

CHARGE CONTROLLER

TYPE :PWM Based

RATING :12.8V NOMINAL, LOAD 2.1A MAX.SMPS FOR LED LOAD

EFFICIENCY :85%

STAND BY CURRENT :OUTPUT VOLTAGE DROP

LUMINAIRE

SYSTEM WATTAGE( LED + DRIVER) :20W

SYSTEM OUT PUT(AFTER ACCOUNTING ALL LOSES) : 4000 Lumens

LED LEVEL EFFICIENCY :200 LUMENS/WATT OSARAM GW JDSTS2.EM Led

LED LIFE :50,000 Hours

DRIVER EFFICIENCY :85%

DRIVER TYPE :DC-DC

TOTAL SYSTEM WARRANTY :3 YEARS WARRANTY

HOUSI :IP 65 ALUMINIUM DIE-CAST HOUSING, IP66

LUMINAIRE ARM :Powder Coated

SOLAR PANEL

CAPACITY :60 Wp

SOLAR CELLS :POLYCRYSTALLINE SILICON CELSS

SOLAR CELL EFFICIENCY :13.50%

JUNCTION BOX :IP65, IP66

MOUNTING FRAME :POWDER COATED

COUNTRY OF MANUFACTURER :INDIA

BATTERY AND BATTERY BOX

CAPACITY :18000 mAh LIFePo4 BATTERY

TYPE :Lithium Ferrous Phosphate Battery

PERMITTED DEPTH OF DISCHARGE :70%

BATTERY BACKUP :12 HOURS

MOUNTING POSITION :IN BUILT BOX WITH P.V. PANEL STRUCTURE

BATTERY BOX MATERIAL & PROTECTION :M.S. SHEET WITH POWDER COATED 1 mm THK

CHARGE CONTROLLER

TYPE :PWM Based

RATING :12.8V NOMINAL, LOAD 2.1A MAX.SMPS FOR LED LOAD

EFFICIENCY :85%

STAND BY CURRENT :OUTPUT VOLTAGE DROP

LUMINAIRE

LUMINAIRE

SOLAR PANEL

BATTERY AND BATTERY BOX

CHARGE CONTROLLER

POLE

SYSTEM REQUIREMENTS

ELECTRICAL DATA @STC

Model: INV 020

Maximum Power Pmpp [Wp]: 20

Maximum Power Tolerance (%): +≥1%

Voltage at maximum Power Vmpp[V]: 17.60

Open circuit Voltage Voc [V]: 21.3

Current at maximum Power Impp [A]: 1.14

Short circuit Current Isc [A]: 1.24

NOCT [deg. C]: ±2 45

Module Efficiency [%]: 13.0%

Cells Efficiency: 18%

Number of Cells: 36

The Electrical characteristics are at Standard Test Conditions (STC: irradiance of 1000 W/m2, AM 1.5 spectrum, and a cell temperature of 25°C/77°F)

Input: 240V AC

Out Put: 240V AC Sine wave

Power: 700 KVA

Battery: 12V
